- Camera
- Main Stream25 fps (1920 × 1080, 1280 × 720)
- Sub Stream25 fps (704 × 576，640 × 480)
- Min. IlluminationColor: 0.01 Lux@(F2.0, AGC ON)
- Image SettingsSaturation, brightness, contrast, sharpness, AGC and white balance can be adjusted through the client or browser.
- Adjusted AngleHorizontal: 0° ~ 360°; Vertical: 0° ~ 70°; rotated: 0° ~ 360°
- WDRDigital WDR
- Shutter1/25 ~ 1/100,000 s
- Day/Night SwitchIR cut filter
- Image EnhancementBLC, 3D DNR
- SVC EncodingH.264, H.265
- H.265Main Profile
- H.264Main Profile/High Profile
- Main Stream Video Compression StandardH.265;H.264
- Sub Stream Compression StandardH.265;H.264
- Video Bitrate256 Kbps ~ 4 Mbps
- GeneralAnti-banding, Heartbeat, Mirror, Password protection, Video occlusion
- Intelligent AlarmHigh temperature alarm, Differential temperature alarm
- Exception DetectionNetwork cable disconnection, IP address conflict, Invalid access
- WEB ConfigurationSupport web preview, configuration
- ProtocolTCP/IP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IPv4, UDP
- Interface ProtocolONVIF(PROFILE S, PROFILE G), ISAPI，EZVIZ
- Power Comsumption≤ 6.5 W
- IR Range30m
- Accessory TypeWall mount, Pendant mount, Junction box
Focal Length & FOV
2.8mm,horizontal FOV: 105.12°, vertical 59.13°, diagonal FOV: 120.6°
4mm,horizontal FOV:78.96°, vertical 43.17°, diagonal FOV: 93.31°
- Detector
- Temperature Sensing ModeThermistor
- Thermography Alarm Shielded AreaConfigure four rectangular areas
- Image Sensor1/2.9" Progressive Scan CMOS
- High Temperature AlarmYes
- Max. Resolution1920 × 1080
- Alarm Indicator LightOne, Red: Alarm; Yellow: Fault; Green: Normal
- Thermography Precision±3°(In a constant temperature environment without wind, power on for 1 hour)
- Function
- Remote SilenceYes
- Interface
- Audio Interface1 built-in microphone
- Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- General
Using Environment
Temperature: -30 ℃ ~ 60 ℃
Humidity: less than 95% (no condensing)
- Dimension (φ × H)Φ 109.9 × H 106.5 mm
- WeightApprox. 290g, 452g with package
- Execution StandardQ/HKD 006-2019
- Mounting HeightWall mounted: 2.4 m~2.8 m; Pendent: 3.3 m~6 m
- Ingress ProtectionIP66
Power
DC 12V
POE: IEEE802.3af, CLASS 3
