- Speaker
Rated Power
70 V: 5 W/10 W/15 W/20 W
100 V: 5 W/10 W/15 W/20 W
- Impedance8 Ω
- Max. Acoustic Pressure103 dBSPL
- Sensitivity(1 m, 1 W)90 dB ± 3dB
- DirectionAll directions
- Frequency Response130 Hz to 17.5 kHz
- Speaker Unit5.25′′ × 1
Coverage Angle
Horizontal: 135°
Vertical: 130°
- Interface
- Audio InFixed pressure in 100 V/Fixed pressure in 70 V/Fixed resistance input 8 Ω × 1
- General
- MaterialMain body&Front cover：plastic, bracket: metal
- Operating Temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Operating Humidity＜90% (No condensation)
- Dimension268.4 mm × 180.4 mm × 125.12 mm (10.57" × 7.1" × 4.93")
- Package Dimension340 mm × 306 mm × 180 mm (13.39" × 12.05" × 7.09")
- Approx. 1.5 kg (3.3 lb.)
- ColorWhite or black appearance optional
- With Package WeightApprox. 2 kg (4.4 lb.)
Packing List
Device × 1
U-shaped bracket × 1
Screw pack × 1
Installation sticker × 1
Regulatory Compliance and Safety Information × 1
