- System
- Operation systemLinux
- Display
- Dimensions4.3-inch
- Resolution272 × 480
- TypeLCD
- Operation methodCapacitive touch screen
- Video
- Pixel2 MP
- Lens× 2
- Video standardPAL (Default) and NTSC
- Network
- Wired network10 M/100 M self-adaptive
- Wi-FiSupport
- Interface
- PoEIEEE802.3at, standard PoE
- Network interface1
- RS-4851
- Wiegand1
- Lock output1
- Exit button1
- Door contact input1
- TAMPER1
- USB1
- Capacity
- Card capacity3,000
- Face capacity1,500
- Fingerprint capacity3,000
- Event capacity150,000
- Authentication
- Card typeM1 card
- Card reading frequency13.56 MHz
- Face recognition duration＜ 0.2 s
- Face recognition accuracy rate＞99%
- Face recognition distance0.3 to 1.5 m
- Fingerprint recognition duration＜1 s
- General
Power supply
Power input: Power interface (power adapter included, 12 VDC/1 A) or PoE (37 to 57 VDC/0.6 A)
Power output: Power supply for door lock, 12 VDC/1 A (only when the device is powered by PoE supporting powering supply for door lock)
- Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity0 to 90% (No condensing)
- Dimensions91.3 mm × 181.3 mm × 24.5 mm (3.59" × 7.14" × 0.96")
- InstallationWall Mounting
- Protective levelIP65
- LanguageEnglish, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean
Gross weight: 0.93 kg (2.05 lbs)
Net weight: 0.36 kg (0.79 lbs)
- Function
- Face anti-spoofingSupport
- Audio promptSupport
- Time synchronizationSupport
