| Basic | |
| Layer | Unmanaged |
| Switching Capacity | 5.6 Gbps |
| Packet Forwarding Rate | 4.168 Mpps |
| Description of Function Slots | Port 1-8: 8 × RJ45 10/100 Mbps (PoE) Port 9-10: 2 × RJ45 10/100/1000 Mbps (Uplink) |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Operating Humidity | 10%–90% (RH), non-condensing |
| Storage Temperature | –40 °C to +75 °C (–40 °F to +167 °F) |
| Storage Humidity | 5%–95% (RH), non-condensing |
| Power Supply | External power supply: 53 V, 50/60 Hz, max 1.81 A |
| Power Consumption | Idling: 2.1 W Full load: 94.2 W |
| Statics Protection | Air discharge: 8 kV Contact discharge: 6 kV |
| Lightning Protection | Common mode: 6 kV Differential mode: 1 kV |
| Net Weight | 0.3 kg (0.66 lb) |
| Gross Weight | 0.882 kg (1.94 lb) |
| Product Dimensions | 184.6 mm × 77.4 mm × 27 mm (7.27" × 3.32" × 1.06") (L × W × H) |
| Packaging Dimensions | 253 mm × 112 mm × 83 mm (9.96" × 4.41" × 3.27") (L × W × H) |
| Casing Material | Sheet Metal |
| Installation | Desktop mount; wall mount |
| Certifications | CE |
| PoE | |
| PoE | Yes |
| PoE Power | Port 1-8≤30 W, total≤90 W |
| PoE Protocol | IEEE 802.3af; IEEE 802.3at |
| PoE Pin Assignment | 1,2,4,5 (V+),3,6,7,8 (V-) |
| Long Distance PoE Transmission | Yes |
| Hardware | |
| DIP Switch | Long Distance PoE: The transmission distance of ports 1–8 can reach up to 250 meters. The negotiation speed can be reduced to 10 Mbps. |
| Performance | |
| Packet Buffer Size | 1 Mbits |
| Jumbo Frame | 9216 Byte |
| MAC Table Size | 2K |
| Communication Standard | IEEE802.3; IEEE802.3u; IEEE802.3ab; IEEE802.3x |
| General | |
| Packing List | 1 × User Manual 1 × Legal and Regulatory Information 1 × Power Cord 1 × Power Adapter |
