| Camera | |||||
| Image Sensor | Channel 1 (PT Lens): 1/3" CMOS Channel 2 (Fixed Lens): 1/3" CMOS | ||||
| Max. Resolution | Channel 1 (PT Lens): 2560 (H) × 1440 (V) Channel 2 (Fixed Lens): 2560 (H) × 1440 (V) | ||||
| ROM | 128 MB | ||||
| RAM | 512 MB | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||
| Min. Illumination | 0.008 [email protected] (Color,30 IRE) 0.0008 [email protected]( B/W,30 IRE) 0 lux (Illuminator on) | ||||
| S/N Ratio | >56 dB | ||||
| Illumination Distance | Up to 30 m (98.43 ft) (IR) Up to 30 m (98.43 ft) (Warm light) | ||||
| Illuminator On/Off Control | Auto; Manual | ||||
| Illuminator Number | 4 (IR LED); 4 (Warm light) | ||||
| Lens | |||||
| Lens Type | Channel 1 (PT Lens): Fixed-focal Channel 2 (Fixed Lens): Fixed-focal | ||||
| Lens Mount | M12 | ||||
| Focal Length | Channel 1 (PT Lens): 3.6 mm Channel 2 (Fixed Lens): 3.6 mm | ||||
| Max. Aperture | Channel 1 (PT Lens): F1.6 Channel 2 (Fixed Lens): F1.6 | ||||
| Field of View | Channel 1 (PT Lens): H: 78°; V: 42°; D: 92° Channel 2 (Fixed Lens): H: 78°; V: 42°; D: 92° | ||||
| Iris Control | Fixed | ||||
| Close Focus Distance | Channel 1 (PT Lens): 1.5 m (4.92 ft) Channel 2 (Fixed Lens): 1.5 m (4.92 ft) | ||||
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| Channel 1 (PT Lens) | 78.0 m (255.91 ft) | 31.2 m (102.36 ft) | 15.6 m (51.18 ft) | 7.8 m (25.59 ft) | |
| Channel 2 (Fixed Lens) | 78.0 m (255.91 ft) | 31.2 m (102.36 ft) | 15.6 m (51.18 ft) | 7.8 m (25.59 ft) | |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. | |||||
| Intelligence | |||||
| SMD | SMD Plus | ||||
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | ||||
| Video | |||||
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by sub stream) | ||||
| Smart Codec | Smart H.265+; Smart H.264+ | ||||
| Video Frame Rate | Channel 1 (PT Lens): Main stream: 2560 × 1440@(1–25 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–25 fps) Channel 2 (Fixed Lens): Main stream: 2560 × 1440@(1–25 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–25 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. | ||||
| Streaming Capability | 2 streams | ||||
| Resolution | Channel 1 (PT Lens): 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240); Channel 2 (Fixed Lens): 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | ||||
| Bit Rate Control | VBR; CBR | ||||
| Video Bit Rate | H.264: 32 kbps–6144 kbps; H.265: 32 kbps–6144 kbps | ||||
| Day/Night | Auto(ICR)/Color/B/W | ||||
| BLC | Yes | ||||
| HLC | Yes | ||||
| WDR | 120 dB | ||||
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | ||||
| Gain Control | Auto/Manual | ||||
| Noise Reduction | 3D NR | ||||
| Motion Detection | OFF/ON (4 areas, rectangular) | ||||
| Region of Interest (RoI) | Yes (4 areas) | ||||
| Smart Illumination | Yes | ||||
| Smart Dual Light | Yes | ||||
| Image Rotation | 0°/180° | ||||
| Mirror | Yes | ||||
| Privacy Masking | 4 areas | ||||
| Audio | |||||
| Built-in MIC | Yes, built-in Mic | ||||
| Built-in Speaker | Yes, built-in speaker | ||||
| Audio Compression | G.711a; G.711Mu; PCM; G.726 | ||||
| Alarm | |||||
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD; security exception | ||||
| Network | |||||
| Network Port | RJ-45 (10/100 Base-T) | ||||
| SDK and API | Yes | ||||
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P; Auto Registration | ||||
| Security | HTTPS; Trusted upgrade;Digest; WSSE; Account lockout; Trusted execution; Generation and importing of X.509 certification; Security logs; Trusted boot | ||||
| Interoperability | ONVIF (Profile S & Profile G & Profile T); CGI | ||||
| User/Host | 20 (Total bandwidth: 48 M) | ||||
| Storage | FTP; Micro SD card (support max. 256 GB) | ||||
| Browser | IE; Chrome; Firefox | ||||
| Management Software | Smart PSS Lite; DSS; DMSS | ||||
| Mobile Client | Android;iOS | ||||
| Function | |||||
| Light Warning | Warm light warning Flash/Solid on duration: 5 s–180 s Flash frequency: high, medium, low | ||||
| Sound Warning | Offers 3 sound alarms and supports importing custom sound alarms. Sound: 0-100. Play times can be set from 1 to 10. | ||||
| PTZ | |||||
| Pan/Tilt Range | Channel 1 (PT Lens): Pan: 0° to 350°; Tilt: 0° to 90°; Channel 2 (Fixed Lens): Pan: 0° to 326°; Tilt: –10° to 15° | ||||
| Manual Control Speed | Pan: 0.1°/s–55.4°/s; Tilt: 0.1°/s–29.3°/s | ||||
| Preset | 50 | ||||
| Preset Speed | Pan: 55.4°/s; Tilt: 29.3°/s | ||||
| Power-off Memory | Yes | ||||
| Idle Motion | Preset | ||||
| Certification | |||||
| Certifications | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU | ||||
| Power | |||||
| Power Supply | 12 VDC (±30%); PoE (802.3af) | ||||
| Power Consumption | Basic: 3.2 W (12 VDC); 4.2 W (PoE); Max.: 8.6 W (12 VDC); 10.5 W (PoE) (intelligence on + WDR + illuminator on + PT rotation + speaker on) | ||||
| Environment | |||||
| Operating Temperature | –40 °C to +50 °C (–40 °F to +122 °F) | ||||
| Operating Humidity | ≤95% (RH), non-condensing | ||||
| Storage Temperature | –40 °C to +50 °C (–40 °F to +122 °F) | ||||
| Storage Humidity | ≤95% (RH), non-condensing | ||||
| Protection | IP66 | ||||
| Structure | |||||
| Casing Material | Plastic | ||||
| Product Dimensions | 159.4 mm × 110.1 mm × 210 mm (6.28" × 4.33" × 8.27") (L × W × H) | ||||
| Net Weight | 0.62 kg (1.37 lb) | ||||
| Gross Weight | 0.85 kg (1.87 lb) | ||||
