Camera Image Sensor 1/1.8" CMOS Pixel 4MP Max. Resolution 2688 (H) × 1520 (V) ROM 256 MB RAM 256 MB Electronic Shutter Speed 1–1/100,000 s Scanning System Progressive Min. Illumination 0.0005 [email protected] (Color, 30 IRE); Illumination Distance 3.6 mm: 30 m (98.43 ft) (Warm light) Illuminator On/Off Control Auto; Manual; Off Illuminator Number 4 (Warm light)
Lens Focal Length 3.6 mm Max. Aperture F1.0 Field of View 3.6 mm: H: 97°; V: 52°; D: 114° Close Focus Distance 3.6 mm: 2.6 m (8.53 ft) DORI Distance Lens Detect Observe Recognize Identify 3.6 mm 49.7 m 19.6 m 9.9 m 5.0 m *DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
PTZ Pan/Tilt Range Pan: 0° to 345°; Manual Control Speed Pan: 0.1°–34.5°/s; Tilt: 0.1°–36.4°/s Preset Speed Pan: 0.1°–33.8°/s; Tilt: 0.1°–36.3°/s Preset 80 Tour 8 (up to 6 presets per tour; the stay duration for each preset is 60 to 360 sec and tour interval is 900 to 3,600 sec) Power-off Memory Yes Idle Motion Preset;Tour
Smart Event IVS Tripwire; intrusion Human Detection Yes Vehicle Detection Yes
Intelligence Smart Tracking Auto Tracking Lite SMD SMD 3.0
Active Deterrence Light Warning Warm light warning Sound Warning Offers 3 sound alarm.
Video Video Compression Smart H.265+;H.265;Smart H.264+;H.264B;H.264M;H.264H;MJPEG(Sub Stream 1) Streaming Capability 2 streams Resolution 4M (2688 × 1520);4M (2560 × 1440);3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704×576);VGA(640 × 480); CIF(352 × 288) Video Frame Rate Main stream: 2560 × 1440@(1–25/30 fps) Bit Rate Control CBR/VBR Video Bit Rate H.264: 8 kbps–6,400 kbps Day/Night Color/B/W BLC Yes WDR 120 dB HLC Yes White Balance Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp Gain Control Auto; Manual; Gain Priority Noise Reduction 2D NR; 3D NR Motion Detection Yes Region of Interest (RoI) Yes Defog Electronic Digital Zoom 16 × Image Rotation 180° S/N Ratio ≥55 dB
Audio Audio Compression PCM, G.711A, G.711Mu Built-in MIC Yes Built-in Speaker Yes
Network Network Port RJ-45 (10/100 Base-T) Network Protocol HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;NTP;DHCP;DNS;DDNS;IPv6;SSL;QoS;FTP;ICMP;IGMP;ARP;RTCP;RTP;RTMP Interoperability ONVIF (Profile S & Profile G & Profile T);CGI;SDK Streaming Method Unicast/Multicast User/Host 20 (total bandwidth: 64 M) Storage Micro SD card (Up to 512 GB); FTP Browser IE: IE 7 and later versions; Chrome; Firefox; Safari Management Software DMSS;NVR Mobile Client iOS;Android
Function Certification Port Audio Input 1 channel (built-in mic) Audio Output 1 channel (built-in speaker) Alarm Linkage Capture; recording; audio; light Alarm Event Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection
Power Power Supply 12 VDC, 1A ± 10% PoE (802.3af) Power Consumption PoE: Basic: 3.6 W Max: 9.5 W (illuminator + PTZ) Power Adapter Optional
Environment Operating Temperature –30 °C to +55 °C (–22 °F to +131 °F) Operating Humidity ≤95% Protection IP66;TVS 2000 V lightning proof; surge protection; voltage transient protection
Structure Product Dimensions 153.5 mm × Φ129.3 mm (6.04" × Φ5.09") Net Weight 0.8kg (1.76 lb) Gross Weight 1.2kg (2.64 lb)
