Camera
Image Sensor	1/1.8" CMOS
Pixel	4 MP
Max. Resolution	2560 (H) × 1440 (V)
ROM	256 MB
RAM	256 MB
Electronic Shutter Speed	1 s–1/30,000 s
Scanning System	Progressive
Min. Illumination	0.0005 lux@F1.0 (Color, 30 IRE); 0 lux（illuminator on）
Illumination Distance	4 mm: 30 m (164.04 ft) (Warm light)
Illuminator On/Off Control	Manual; auto; off
Illuminator Number	4 (warm light)
Lens
Focal Length	4 mm
Max. Aperture	F1.0
Field of View	4 mm: H: 97°; V: 52°; D: 114°
Close Focus Distance	4 mm: 2.6 m (8.53 ft)
DORI Distance	Lens Detect Observe Recognize Identify 4 mm 70.34 m ( 230.45 ft) 28.14 m ( 92.24 ft) 14.07 m ( 46.16 ft) 7.03m ( 23.05 ft) *DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
PTZ
Pan/Tilt Range	Pan: 0° to 345°; Tilt: 0° to +90°
Manual Control Speed	Pan: 0.1°–34.5°/s; Tilt: 0.1°–36.4°/s
Preset Speed	Pan: 0.1°–33.8°/s; Tilt: 0.1°–36.3°/s
Preset	300
Tour	8 (up to 32 presets per tour)
Power-off Memory	Yes
Idle Motion	Preset;Tour
Smart Event
IVS	Tripwire and intrusion
Human Detection	Yes
Vehicle Detection	Yes
Intelligence
Smart Tracking	Auto Tracking lite
SMD	SMD 3.0
Active Deterrence
Light Warning	Warm light warning Flash duration: 5 s–30 s; Flash frequency: high, medium, low
Sound Warning	supports importing custom voice content;Sound can be set from 0%–100%. Play times can be set from 1-10.
Video
Video Compression	Smart H.265+;H.265;Smart H.264+;H.264B;H.264M;H.264H;MJPEG
Resolution	4M (2560 × 1440); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Video Frame Rate	Main stream: 4M/1080p/720p@(1–25/30 fps) Sub stream 1: D1/VGA/CIF@(1–25/30 fps)
Bit Rate Control	CBR/VBR
Video Bit Rate	H264: 3,072 kbps–15,104 kbps H265: 1,280 kbps–9,216 kbps
Day/Night	Color/B/W
BLC	Yes
WDR	DWDR
HLC	Yes
White Balance	Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
Gain Control	Auto; manual
Noise Reduction	2D NR; 3D NR
Motion Detection	Yes
Defog	Electronic
Digital Zoom	16 x
Image Rotation	180°
S/N Ratio	≥55 dB
Audio
Audio Compression	PCM, G.711A, G.711Mu
Built-in MIC	Yes
Built-in Speaker	Yes
Network
Network Port	RJ-45 (10/100 Base-T)
Network Protocol	HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;QoS;FTP;UPnP;ICMP;SNMP;IGMP;ARP;RTCP;RTP;PPPoE;RTMP;Bonjour;NFS
Interoperability	ONVIF (Profile S & Profile G & Profile T);CGI;SDK
Streaming Method	Unicast/Multicast
User/Host	20 (total bandwidth: 64 M)
Storage	Micro SD card (Up to 256 GB); FTP
Browser	IE: IE 7 and later versions; Chrome; Firefox; Safari
Management Software	DMSS;5 Series NVR;DSS Pro
Mobile Client	iOS;Android
Function
Abnormal Sound Alarm	Yes
Certification
Certifications	CE
Port
Audio Input	1 channel (built-in mic)
Audio Output	1 channel (built-in speaker)
Alarm Linkage	Capture; preset; recording; audio; sending email
Alarm Event	Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection
Power
Power Supply	12 VDC, 1A ± 10% PoE (802.3af)
Power Consumption	PoE: Basic: 3.6 W Max: 9.5 W (illuminator + PTZ)
Power Adapter	Optional
Environment
Operating Temperature	–30 °C to +55 °C (–22 °F to +131 °F)
Operating Humidity	≤95%
Protection	TVS 2000 V lightning proof; surge protection; voltage transient protection;Waterproof and Dustproof
Structure
Product Dimensions	153.5 mm × Φ129.3 mm (6.04" × Φ5.09")
Net Weight	0.66 kg (1.46 lb)
Gross Weight	1 kg (2.20 lb)
