| Camera | |||||
| Image Sensor | 1/1.8" CMOS | ||||
| Max. Resolution | 2688(H) × 1520 (V) | ||||
| ROM | 256 MB | ||||
| RAM | 1 GB | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||
| Min. Illumination | 0.0001 [email protected](Color,30IRE) 0.0001 [email protected](B/W,30IRE) 0 lux (Illuminator on) | ||||
| S/N Ratio | >56 dB | ||||
| Illumination Distance | Up to 60 m (196.85 ft) (IR) Up to 50 m (164.04 ft) (Warm light) | ||||
| Illuminator On/Off Control | Auto;Manual | ||||
| Illuminator Number | 4 (Multi-core (IR + warm) light) | ||||
| Angle Adjustment | Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° | ||||
| Lens | |||||
| Lens Type | Fixed-focal | ||||
| Lens Mount | M16 | ||||
| Focal Length | 2.8 mm;3.6 mm | ||||
| Max. Aperture | F1.0 | ||||
| Field of View | 2.8 mm: H: 111°; V: 60°; D: 135° 3.6 mm: H: 95°; V: 51°; D: 114° | ||||
| Iris Control | Fixed | ||||
| Close Focus Distance | 2.8 mm: 2.0 m (6.56 ft) 3.6 mm: 3.5 m (11.48 ft) | ||||
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 2.8 mm | 56.6 m (185.70 ft) | 22.6 m (74.75 ft) | 11.3 m (37.07 ft) | 5.7 m (18.70 ft) | |
| 3.6 mm | 69.0 m (226.38 ft) | 27.6 m (90.55 ft) | 13.8 m (45.28 ft) | 6.9 m (22.64 ft) | |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. | |||||
| Intelligence | |||||
| IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human), stay detection, loitering detection. | ||||
| Face Detection(Full Image) | Face detection; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting. | ||||
| SMD | SMD 4.0 | ||||
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | ||||
| AcuPick | Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets. | ||||
| AI SSA | Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions. | ||||
| Video | |||||
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (only supported by sub stream) | ||||
| AI Coding | AI H.265; AI H.264 *Includes smart codec technology, Smart H.265+ and Smart H.264+ | ||||
| Video Frame Rate | Main stream: 2688 × 1520@(1 fps–25/30 fps) Third stream: 1920 × 1080@(1 fps–25/30 fps) | ||||
| Stream Capability | 3 streams | ||||
| Resolution | 4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | ||||
| Bit Rate Control | VBR; CBR; ABR | ||||
| Video Bit Rate | H.264: 3 kbps–16384 kbps H.265: 3 kbps–16384 kbps | ||||
| Day/Night | Auto(ICR)/Color/B/W | ||||
| BLC | Yes | ||||
| HLC | Yes | ||||
| WDR | 120 dB | ||||
| Scene Self-adaptation (SSA) | Yes | ||||
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | ||||
| Gain Control | Auto/Manual | ||||
| Noise Reduction | 3D NR | ||||
| Motion Detection | OFF/ON (4 areas, rectangular) | ||||
| Region of Interest (RoI) | Yes (4 areas) | ||||
| Smart Illumination | Yes | ||||
| Smart Dual Light | Yes | ||||
| Defog | Yes | ||||
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) | ||||
| Mirror | Yes | ||||
| Privacy Masking | 8 areas | ||||
| LDC | Yes | ||||
| Audio | |||||
| Built-in MIC | Yes, built-in dual Mic | ||||
| Built-in Speaker | Yes, built-in speaker Max power consumption: 2 W; max sound level at 10 cm: 110 dB * Test results from laboratory | ||||
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 | ||||
| Alarm | |||||
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; stay detection; loitering detection; face detection (full image); scene changing; audio detection; voltage detection; SMD; security exception | ||||
| Network | |||||
| Network Port | RJ-45 (10/100 Base-T) | ||||
| SDK and API | Yes | ||||
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Bonjour; Auto Registration | ||||
| Interoperability | ONVIF (Profile S & Profile G & Profile T & Profile M); CGI | ||||
| User/Host | 20 (Total bandwidth: 64 M) | ||||
| Storage | FTP;SFTP; Micro SD card (support max. 512 GB); NAS | ||||
| Browser | IE: IE11 Chrome Firefox | ||||
| Management Software | Smart PSS Lite; DSS; DMSS; DoLynk Care | ||||
| Mobile Client | iOS;Android | ||||
| Security | Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; Syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade | ||||
| Certification | |||||
| Certifications | CE-LVD: EN 62368-1; CE-EMC: Electromagnetc Compatbility Directve 2014/30/EU | ||||
| Port | |||||
| Audio Input | 1 channel (RCA port) | ||||
| Audio Output | 1 channel (RCA port) | ||||
| Alarm Input | 1 channel in: wet contact, 5 mA 3–5 VDC | ||||
| Alarm Output | 1 channel out: wet contact, 300 mA 12 VDC | ||||
| Power | |||||
| Power Supply | 12 VDC/PoE+ (802.3at) | ||||
| Dual Power Backup | When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart. | ||||
| Power Consumption | Basic: 4.3 W (12 VDC); 6.2 W (PoE) Max. (H.265 + WDR + warm light+siren and light active deterrence + intelligence on): 11.8 W (12 VDC); 15.1 W (PoE) | ||||
| Environment | |||||
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||
| Operating Humidity | ≤95% (RH), non-condensing | ||||
| Protection | IP67 | ||||
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||
| Storage Humidity | ≤95% (RH), non-condensing | ||||
| Structure | |||||
| Casing Material | Metal + plastic | ||||
| Product Dimensions | 288.4 mm × 94.4 mm × 84.7 mm (11.35" × 3.72"× 3.33")(L × W × H) | ||||
| Net Weight | 1.0 kg (2.20 lb) | ||||
| Gross Weight | 1.3 kg (2.87 lb) | ||||
