| Camera | |||||
| Image Sensor | 1/2.8" CMOS | ||||
| Max. Resolution | 2688 (H) × 1520 (V) | ||||
| ROM | 4 GB | ||||
| RAM | 2 GB | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||
| Min. Illumination | 2.0 mm: 0.005 [email protected] (Color,30 IRE) 0.0005 [email protected] (B/W,30 IRE) 0 lux (Illuminator on) 2.8 mm: 0.005 [email protected](Color, 30 IRE) 0.0005 [email protected] (B/W, 30 IRE) 0 lux (Illuminator on) | ||||
| S/N Ratio | >56 dB | ||||
| Illumination Distance | Up to 20 m (65.62 ft) (IR) | ||||
| Illuminator On/Off Control | Auto;Manual | ||||
| Illuminator Number | 1 (IR LED) | ||||
| Angle Adjustment | Tilt: -10° to 70° | ||||
| Lens | |||||
| Lens Type | Fixed-focal | ||||
| Lens Mount | M12 | ||||
| Focal Length | 2.8 mm;2.0 mm | ||||
| Max. Aperture | 2.0 mm: F2.0 2.8 mm: F1.6 | ||||
| Field of View | 2.0 mm: H: 108°; V: 74°; D: 117° 2.8 mm: H: 87°; V: 55°; D: 97° | ||||
| Iris Control | Fixed | ||||
| Close Focus Distance | 2.0 mm: 0.4 m (1.31 ft) 2.8 mm: 1.1 m (3.61 ft) | ||||
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 2.0 mm | 44.8 m (146.98 ft) | 17.9 m (58.73 ft) | 9.0 m (29.53 ft) | 4.5 m (14.76 ft) | |
| 2.8 mm | 63.6 m (208.66 ft) | 25.4 m ( 83.33 ft) | 12.7 m (41.67 ft) | 6.4 m (21.00 ft) | |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. | |||||
| Smart Event | |||||
| IVS | Abandoned object; missing object | ||||
| Intelligence | |||||
| IVS (Perimeter Protection) | Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection; people gathering; loitering detection; privacy protection | ||||
| Stereo Analysis | Crossing warning line; warning area intrusion; running detection (only supported by inclined mount cameras); people approaching detection; violence detection (including fighting and smashing); fall detection; abnormal number of people detection; people stay detection; privacy protection; height filtering | ||||
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. | ||||
| Video | |||||
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) | ||||
| Smart Codec | Smart H.265+; Smart H.264+ | ||||
| AI Coding | AI H.265; AI H.264 | ||||
| Video Frame Rate | Main stream: 2688 × 1520@(1–25/30 fps) sub stream: 1920 × 1080@(1–25/30 fps) third stream: 1920 × 1080@(1–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. | ||||
| Stream Capability | 3 streams | ||||
| Resolution | 4M (2688 × 1520/2560 × 1440); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | ||||
| Bit Rate Control | ABR;CBR;VBR | ||||
| Video Bit Rate | H.264: 3 kbps–8192 kbps H.265: 3 kbps–8192 kbps | ||||
| Day/Night | Auto(ICR)/Color/B/W | ||||
| BLC | Yes | ||||
| HLC | Yes | ||||
| WDR | DWDR | ||||
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | ||||
| Gain Control | Auto | ||||
| Noise Reduction | 3D NR | ||||
| Motion Detection | OFF/ON (4 areas, rectangular) | ||||
| Region of Interest (RoI) | Yes (4 areas) | ||||
| Image Stabilization | Electronic Image Stabilization (EIS) | ||||
| Smart Illumination | Yes | ||||
| Defog | Yes | ||||
| Privacy Masking | 8 areas | ||||
| Audio | |||||
| Built-in MIC | Yes, built-in Mic | ||||
| Built-in Speaker | Yes, built-in speaker | ||||
| Audio Compression | G.711a; G.711Mu; PCM; G.726; G.723 | ||||
| Alarm | |||||
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; voltage detection; illegal access; motion detection; video tampering; scene changing; audio detection; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; crossing warning line; warning area intrusion; running detection; abnormal number of people detection; fall detection; people approaching detection; violence detection; people stay detection | ||||
| Network | |||||
| Network Port | RJ-45 (10/100/1000 Base-T) | ||||
| SDK and API | Yes | ||||
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; auto registration | ||||
| Interoperability | ONVIF (Profile S; Profile G; Profile T); P2P; CGI | ||||
| User/Host | 20 | ||||
| Storage | FTP; SFTP; Micro SD card (support max. 512 GB); NAS | ||||
| Browser | IE: IE 9 and later Chrome: Chrome 41 and later Firefox: Firefox 50 and later Safari: Safari 10 and later | ||||
| Management Software | Smart PSS Lite; DSS; DMSS | ||||
| Mobile Client | iOS;Android | ||||
| Cyber Security | Configuration encryption;Trusted execution;Session security;Digest;Security logs;WSSE;Account lockout;Security warning;syslog;Video encryption;802.1x;IP/MAC filtering;HTTPS;Trusted upgrade;Trusted boot;Firmware encryption;Generation and importing of X.509 certification | ||||
| Certification | |||||
| Certifications | CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU | ||||
| Port | |||||
| RS-485 | 1 (baud rate range: 1200 bps–115200 bps) | ||||
| Audio Input | 2 channels (RCA port) | ||||
| Audio Output | 1 channel (RCA port) | ||||
| Alarm Input | 2 channels in: wet contact, 5 mA 3–5 VDC | ||||
| Alarm Output | 2 channels out: wet contact, 300 mA 12VDC | ||||
| Analog Output | 1 channel (CVBS output: BNC) | ||||
| Power Output | 12 VDC power output, max. current 165 mA, peak current 700 mA | ||||
| Power | |||||
| Power Supply | 12 VDC/PoE (802.3af)/ePoE | ||||
| Power Consumption | Basic: 5.9 W (12 VDC), 7 W (PoE); Max. (intelligence on + IR intensity + turn on the speaker+ power output): 10.8 W (12 VDC), 12.9 W (PoE) | ||||
| Environment | |||||
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||
| Operating Humidity | ≤95% (RH), non-condensing | ||||
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||
| Storage Humidity | ≤95% (RH), non-condensing | ||||
| Protection | IP67; IK10 | ||||
| Structure | |||||
| Casing Material | Metal | ||||
| Product Dimensions | 204.0 mm × 78.0 mm × 61.6 mm (8.03" × 3.07" × 2.43") (L × W × H) | ||||
| Net Weight | 0.82 kg (1.81 lb) | ||||
| Gross Weight | 1.14 kg (2.51 lb) | ||||
