| Camera | ||||
| Image Sensor | 1/2.8" CMOS | |||
| Pixel | 4 MP | |||
| Max. Resolution | 2560 (H) × 1440 (V) | |||
| ROM | 128 MB | |||
| RAM | 512 MB | |||
| Electronic Shutter Speed | 1/1 s–1/30,000 s | |||
| Scanning System | Progressive | |||
| Min. Illumination | Color: 0.005 [email protected] B/W: 0.0005 [email protected] 0 lux (illuminator on) | |||
| Illumination Distance | 100 m (328.08 ft) (IR) | |||
| Illuminator On/Off Control | Zoom Prio; Manual; Auto; Off | |||
| Illuminator Number | 3 (IR) | |||
| Lens | ||||
| Focal Length | 5 mm–125 mm | |||
| Max. Aperture | F1.6–F3.6 | |||
| Field of View | H: 51.9°–3.0°; V: 39.7°–2.2°; D: 63.1°–3.7° | |||
| Optical Zoom | 25× | |||
| Focus Control | Auto; semi-auto; manual | |||
| Close Focus Distance | 0.1 m–0.5 m (0.33 ft–1.64 ft) | |||
| Iris Control | Auto; manual | |||
| DORI Distance | Detect | Observe | Recognize | Identify |
| 2500 m (8208.10 ft) | 987.5 m (3239.83 ft) | 500 m (1640.42 ft) | 250 m (820.21 ft) | |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. | ||||
| PTZ | ||||
| Pan/Tilt Range | Pan: 0° to 360° endless Tilt: –15° to +90°, auto flip 180° | |||
| Manual Control Speed | Pan: 0.1°/s–80°/s Tilt: 0.1°/s–80°/s | |||
| Preset Speed | Pan: 80°/s; Tilt: 80°/s | |||
| Preset | 300 | |||
| Tour | 8 (up to 32 presets per tour) | |||
| Pattern | 5 | |||
| Scan | 5 | |||
| Power-off Memory | Yes | |||
| Idle Motion | Pattern; Preset; Scan; Tour | |||
| Intelligence | ||||
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification | |||
| Face Detection | Supports face detection, capturing snapshots, and enhancing face images. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing and quality first | |||
| SMD | SMD 3.0 | |||
| Auto Patrol | It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets | |||
| Video | ||||
| Video Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+ | |||
| Streaming Capability | 3 streams | |||
| Resolution | 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576); VGA (640 × 480)/CIF (352 × 288/352 × 240) | |||
| Video Frame Rate | Main stream: 4M/3M/1080p/1.3M/720p@(1–25/30 fps) Sub stream 1: D1/CIF/VGA@(1–25/30 fps) Sub stream 2: 720p@(1–25/30 fps) | |||
| Bit Rate Control | CBR/VBR | |||
| Video Bit Rate | H.264: 96 kbps–14848 kbps H.265: 38 kbps–8960 kbps | |||
| Day/Night | Auto (ICR)/Color/B/W | |||
| BLC | Yes | |||
| WDR | 120 dB | |||
| HLC | Yes | |||
| White Balance | Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp | |||
| Gain Control | Auto; manual | |||
| Noise Reduction | 2D NR; 3D NR | |||
| Motion Detection | Yes | |||
| Region of Interest (RoI) | Yes | |||
| Image Stabilization | Electronic (EIS) | |||
| Defog | Electronic | |||
| Digital Zoom | 16× | |||
| Image Rotation | 180° | |||
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view; multiple colors available | |||
| S/N Ratio | ≥55 dB | |||
| Audio | ||||
| Audio Compression | PCM; G.711A; G.711MU; G.726; AAC; MPEG2-Layer2; G.722.1 | |||
| Network | ||||
| Network Port | RJ-45 (10/100 Base-T) | |||
| Network Protocol | FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE; NTP;RTP;802.1x;HTTPS;SNMP;TCP/IP;DDNS;UPnP; NFS;ICMP;UDP;IGMP;SMB;HTTP;SSL;DHCP;SMTP; Qos;RTSP;ARP | |||
| Interoperability | ONVIF(Profile S&G&T);CGI;SDK | |||
| Streaming Method | Unicast/Multicast | |||
| User/Host | 20 (total bandwidth: 64 M) | |||
| Storage | FTP/SFTP; Micro SD card (512 GB); NAS | |||
| Browser | IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions Safari 10 and later versions | |||
| Management Software | DSS; NVR; Smart PSS;IVSS | |||
| Mobile Client | iOS; Android | |||
| Certification | ||||
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4- 2014 | |||
| Port | ||||
| Audio Input | 1 channel | |||
| Audio Output | 1 channel | |||
| Alarm Linkage | Capture; recording; send email; preset; pattern; tour; alarm digital input | |||
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection | |||
| Alarm I/O | 2/1 | |||
| Audio I/O | 1/1 | |||
| Power | ||||
| Power Supply | 12 VDC, 3 A ± 10% POE+ (802.3at) | |||
| Power Consumption | Basic: 8 W Max: 21 W (illuminator + heater + PTZ) | |||
| Environment | ||||
| Operating Temperature | –40 °C to +65 °C (–40 °F to +149 °F) | |||
| Operating Humidity | ≤95% | |||
| Protection | IP66, TVS 6000 V lightning proof; surge protection; voltage transient protection | |||
| Structure | ||||
| Product Dimensions | 270.4 mm × Φ160 mm (10.65" × Φ6.30") | |||
| Net Weight | 2.4 kg (5.29 lb) | |||
| Gross Weight | 3.3 kg (7.28 lb) | |||
