| Camera | ||||||||||||||||
| Image Sensor | 1/2.7" CMOS (×2) | |||||||||||||||
| Max. Resolution | 4096 (H) × 1860 (V) | |||||||||||||||
| ROM | 128 MB | |||||||||||||||
| RAM | 1 GB | |||||||||||||||
| Scanning System | Progressive | |||||||||||||||
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | |||||||||||||||
| Min. Illumination | 0.005 [email protected] (Color, 30 IRE) 0.0005 [email protected] (B/W, 30 IRE) 0 lux (Illuminator on) | |||||||||||||||
| S/N Ratio | >56 dB | |||||||||||||||
| Illumination Distance | 2.8 mm: Up to 25 m (82.02 ft) (IR) Up to 20 m (65.62 ft) (Warm light) | |||||||||||||||
| Illuminator On/Off Control | Auto;Manual | |||||||||||||||
| Illuminator Number | 2 (IR LED); 2 (Warm light) | |||||||||||||||
| Angle Adjustment | Pan: 0°–360° Tilt: 0°–77° Rotation: 0°–360° | |||||||||||||||
| Lens | ||||||||||||||||
| Lens Type | Fixed-focal | |||||||||||||||
| Lens Mount | M12 | |||||||||||||||
| Focal Length | 2.8 mm | |||||||||||||||
| Max. Aperture | F1.4 | |||||||||||||||
| Field of View | 2.8 mm: H: 180°; V: 86° | |||||||||||||||
| Iris Control | Fixed | |||||||||||||||
| Close Focus Distance | 2.8 mm: 0.8 m (2.62 ft) | |||||||||||||||
| DORI Distance |
| |||||||||||||||
| Intelligence | ||||||||||||||||
| EPTZ | Enlarge and track the targets of intelligent alarms | |||||||||||||||
| IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) | |||||||||||||||
| SMD | SMD 3.0 | |||||||||||||||
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | |||||||||||||||
| Video | ||||||||||||||||
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) | |||||||||||||||
| Smart Codec | Smart H.265+; Smart H.264+ | |||||||||||||||
| Video Frame Rate | Main stream: 4096 × 1860@(1–20 fps) Sub stream: 1200 × 536@(1–20 fps) Third stream: 1920 × 860@(1–20 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. | |||||||||||||||
| Streaming Capability | 3 streams | |||||||||||||||
| Resolution | 8M (4096 × 1860); 6M (3632 × 1632); 4M (3040 × 1368); 1200 × 536; 1920 × 860; 960 × 432; D1 (704 × 576/704 × 480) | |||||||||||||||
| Bit Rate Control | VBR;CBR | |||||||||||||||
| Video Bit Rate | H.264: 6 kbps–16384 kbps; H.265: 6 kbps–16384 kbps | |||||||||||||||
| Day/Night | Auto(ICR)/Color/B/W | |||||||||||||||
| BLC | Yes | |||||||||||||||
| HLC | Yes | |||||||||||||||
| WDR | 120 dB | |||||||||||||||
| Scene Self-adaptation (SSA) | Yes | |||||||||||||||
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | |||||||||||||||
| Gain Control | Auto/Manual | |||||||||||||||
| Noise Reduction | 3D NR | |||||||||||||||
| Motion Detection | OFF/ON (4 areas, rectangular) | |||||||||||||||
| Region of Interest (RoI) | Yes (4 areas) | |||||||||||||||
| Smart Illumination | Yes | |||||||||||||||
| Smart Dual Light | Yes | |||||||||||||||
| Defog | Yes | |||||||||||||||
| Privacy Masking | 4 areas | |||||||||||||||
| Audio | ||||||||||||||||
| Built-in MIC | Yes, built-in dual Mic | |||||||||||||||
| Built-in Speaker | Yes, built-in speaker;Max power consumption: 2 W; max sound level at 10 cm: 110 dB * Test results from laboratory | |||||||||||||||
| Audio Compression | G.711a; G.711Mu; G.726; PCM | |||||||||||||||
| Alarm | ||||||||||||||||
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception | |||||||||||||||
| Network | ||||||||||||||||
| Network Port | RJ-45 (10/100 Base-T) | |||||||||||||||
| SDK and API | Yes | |||||||||||||||
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; P2P | |||||||||||||||
| Interoperability | ONVIF (Profile S & Profile G & Profile T & Profile M); CGI | |||||||||||||||
| User/Host | 20 (Total bandwidth: 64 M) | |||||||||||||||
| Storage | FTP; SFTP; Micro SD card (support max. 512 GB); NAS | |||||||||||||||
| Browser | IE: IE 8 and later; Chrome; Firefox | |||||||||||||||
| Management Software | SmartPSS Lite; DSS; DMSS; DoLynk Care | |||||||||||||||
| Mobile Client | iOS;Android | |||||||||||||||
| Security | Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade | |||||||||||||||
| Function | ||||||||||||||||
| Light Warning | Warm light warning Flash/Solid on duration: 5 s–30 s Flash frequency: high, medium, low | |||||||||||||||
| Sound Warning | Offers 11 sound alarms and supports importing 10 custom sound alarms Sound: 0–100 Play times can be set from 1 to 10 | |||||||||||||||
| Certification | ||||||||||||||||
| Certifications | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU | |||||||||||||||
| Power | ||||||||||||||||
| Power Supply | 12 VDC (±30%); PoE (802.3af) | |||||||||||||||
| Power Consumption | Basic: 4.5 W (12 VDC); 5.3 W (PoE); Max.: 9.7 W (12 VDC); 11.2 W (PoE) (H.265 + WDR + light on + intelligence on) | |||||||||||||||
| Environment | ||||||||||||||||
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | |||||||||||||||
| Operating Humidity | ≤ 95% (RH), non-condensing | |||||||||||||||
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | |||||||||||||||
| Storage Humidity | ≤ 95% (RH), non-condensing | |||||||||||||||
| Protection | IP67 | |||||||||||||||
| Anti-corrosion Level | Basic Protection *The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection. | |||||||||||||||
| Structure | ||||||||||||||||
| Casing Material | Metal | |||||||||||||||
| Product Dimensions | 135.2 mm × Φ122.0 mm (5.32" × Φ4.80") | |||||||||||||||
| Net Weight | 0.95 kg (2.09 lb) | |||||||||||||||
| Gross Weight | 1.11 kg (2.45 lb) | |||||||||||||||
